Description
|
Part Number
|
|
Bush
|
DL12.06(E), U21.2226
|
|
Piston screw
|
2E36.48, 2E36.47A
|
|
Hex.socket head cap screw
|
M12X30DIN912-8.8
|
|
Spring washer
|
12DIN7980
|
|
Gasket
|
DL12.08
|
|
O-Ring
|
86X6
|
|
Spacer tube
|
2E22.06
|
|
Spacer ring
|
2E22.12
|
|
Spacer ring
|
2E22.07
|
|
Cover
|
2E22.16
|
|
Cover
|
2E22.15
|
|
Spacer ring
|
2E22.08A
|
|
Cylinder pin
|
6M6X16DIN7
|
|
Grease nipple
|
R1/4ZDIN3404-M1
|
|
Toothed disc
|
FZI16,5DIN6797
|
|
Hex.socket head cap screw
|
M16X35DIN6912-10.9
|
|
Nex. nut
|
M42X1,5DIN934-8
|
|
Disc
|
2E32.05
|
|
Bush
|
2E34.210
|
|
Piston
|
W37.2095
|
|
Disc
|
2E34.211
|
|
Flange
|
2E22.11, DL22.11
|
|
Flange
|
2E22.09
|
|
Pin
|
2E32.63A
|
|
Pin
|
E36.65B
|
|
Pin
|
2E33.62
|
|
Connecting rod bolt
|
G20.13
|
|
Spacer sleeve
|
2E31.02A
|
|
Bush
|
G20.26B
|
|
Hex.socket head cap screw
|
M10X25DIN6912-8.8
|
|
Seal ring
|
DL12.22
|
|
Closing cylinder
|
CU12.551
|
|
Closing cylinder
|
CU12.501
|
|
Piston rod
|
JT30.06A, E36.42C
|
|
Castle nut
|
M24X1,5DIN937-6
|
|
Cover plate for squeezing cylinder
|
W37.1294
|
|
Gland bush for squeezing cylinder
|
W37.1293
|
|
Thrust washer
|
W37.1440, W37.2040
|
|
Bearing bush
|
2W31.205
|
|
Bush
|
W33.159
|
|
Spacer ring
|
WN121.65.1.85.24.6.1
|
|
Support ring
|
U21.720
|
|
Axle
|
UD15.310
|
|
Bolt
|
DL151.13
|
|
Rubber ring
|
W33.83
|
|
Bolt
|
CU21.3110-8
|
