Pos.
No.
|
Description
|
Part Number
|
Req’d
|
|
3
|
Piston rod
|
2E35.306
|
4
|
|
4
|
Cover
|
2E35.314
|
4
|
|
5
|
Bearing bush
|
2E33.25, 2E35.211
|
4
|
|
6
|
Piston screw
|
2E36.48, 2E36.47A
|
4
|
|
7
|
Piston
|
2E35.303
|
4
|
|
8
|
Closing cylinder
|
HZSI-A.63.402,
|
2
|
|
HZSI-A.57,5.404*
|
|||
|
8
|
Closing cylinder
|
2E34.202B
|
2
|
|
9
|
Flange
|
2E22.09
|
4
|
|
11
|
Support ring
|
U21.720
|
-
|
|
12
|
Spacer ring
|
2E22.08A
|
4
|
|
13
|
Cover
|
2E22.15
|
4
|
|
14
|
Spacer tube
|
2E22.06
|
4
|
|
15
|
Cover
|
2E22.16
|
2
|
|
16
|
Closing cylinder
|
HZSI-G.63.401,
|
2
|
|
HZSI-G.57,5.403*
|
|||
|
16
|
Closing cylinder
|
2E33.21
|
2
|
|
17
|
Flange
|
2E22.11, DL22.11
|
2
|
|
22
|
Hex. socket head cap screw
|
DIN912:M10X25
|
64
|
|
25
|
Hex. socket head cap screw
|
DIN6912:M16X35
|
16
|
|
26
|
Toothed disc
|
DIN6797-FZI 16,5
|
16
|
|
27
|
Spring washer
|
DIN7980-10
|
64
|
|
30
|
Cylinder pin
|
6M6X16DIN7
|
4
|
|
31
|
Threaded pin
|
M6X8DIN914-45H
|
4
|
|
37
|
Spacer ring
|
2E22.07
|
2
|
|
38
|
Spacer ring
|
2E22.12
|
2
|
|
41
|
Seal kit
|
HZS-DS.401
|
4
|
|
45
|
Cover
|
DL12.51
|
4
|
|
47
|
Bush
|
DL12.06
|
4
|
|
50
|
Tamping arm
|
2E34.212A
|
4
|
|
51
|
Tamping arm
|
2E34.213A
|
4
|
|
52
|
Bush
|
2E34.210
|
16
|
|
53
|
Spacer sleeve
|
2E31.02A
|
8
|
|
54
|
Pin
|
2E31.04
|
8
|
|
55
|
Bush
|
G20.26B
|
12
|
|
56
|
Connecting rod bolt
|
G20.13
|
8
|
|
63
|
42 mm Washer/ Disc
|
2E32.05
|
8
|
|
64
|
M42 X 1,5 mm Nut
|
DIN934-42X1,5
|
8
|
|
65
|
Spring washer
|
B24DIN127
|
12
|
|
66
|
Hex. Nut
|
M24X1,5DIN934-8
|
12
|
|
67
|
Disc
|
25DIN1440
|
12
|
|
68
|
Spring washer
|
B42DIN127
|
8
|
|
69
|
Gasket
|
DL12.08
|
-
|
|
75
|
M42 X 1,5 mm Castle Nut
|
2E22.36
|
1
|
|
76
|
42 mm Disc
|
2E22.35
|
1
|
|
78
|
Fittink key
|
2E22.31
|
4
|
|
88
|
Seal ring
|
DL12.22
|
16
|
|
89
|
Disc
|
2E34.211
|
16
|
|
91
|
Flywheel
|
2E22.10A
|
1
|
|
96
|
O-Ring
|
86X6
|
4
|
|
-
|
GREASE NIPPLE
|
R1/4ZDIN3404-M1
|
32
|
|
-
|
Pin
|
2E32.63A
|
4
|
|
-
|
Pin
|
2E33.65
|
4
|
|
-
|
Pin
|
2E33.62
|
4
|
|
-
|
Flap stop
|
2E33.70
|
4
|
|
-
|
Hex bolt special
|
E60.08 ASS
|
4
|
|
-
|
Disc
|
10DIN1440
|
-
|
