| Bush |
DL12.06(E), U21.2226 |
| Piston screw |
2E36.48, 2E36.47A |
| Hex.socket head cap screw |
M12X30DIN912-8.8 |
| Spring washer |
12DIN7980 |
| Gasket |
DL12.08 |
| Spacer ring |
2E22.12 |
| Cover |
2E22.16 |
| Cover |
2E22.15 |
| Grease nipple |
R1/4ZDIN3404-M1 |
| Toothed disc |
FZI16,5DIN6797 |
| Hex.socket head cap screw |
M16X35DIN6912-10.9 |
| Flywheel |
2E22.10A |
| Fittink key |
2E22.31 |
| Nex. nut |
M42X1,5DIN934-8 |
| Spacer ring |
2E34.55 |
| Bush |
2E34.210 |
| Piston rod bush |
2E34.231 |
| Piston |
2E35.303 |
| Disc |
2E34.211 |
| Flange |
2E22.11, DL22.11 |
| Pin |
2E32.63A |
| Pin |
2E33.65 |
| Pin |
2E33.62 |
| Pin |
2E31.04 |
| Connecting rod bolt |
G20.13 |
| Spacer sleeve |
2E31.02A |
| Bush |
G20.26B |
| Disc |
2E34.228 |
| Hex.socket head cap screw |
M10X25DIN6912-8.8 |
| Seal ring |
DL12.22 |
| Closing cylinder |
UD19.1291 |
| Closing cylinder |
UD19.1281 |
| Closing cylinder |
2E34.41A |
| Piston rod |
2E35.306 |
| Cover |
2E35.314 |
| Cover |
2E34.50 |
| Seal kit |
HZS-DS.243, HZS-DS.52(А) |
| Castle nut |
M24X1,5DIN937-6 |
| Spacer ring |
UD25.908(A) |
| Vibration shaft key |
UD22.350 |
| Spacer ring |
WN121.65.1.85.24.6.1 |
| Spacer ring |
WN121.65.1.85.16.1 |
| Flange |
UD25.909(A) |
| Support ring |
U21.720 |
| Spacer ring |
UD25.306 |
| Spacer ring |
UD25.307 |
| Rod bearing bush |
UD19.285, UD19.287 |
| Piston for rod |
2E36.457 |
| Spacer bush |
UD19.222 |
